Global ADN No.1! (Application Delivery Network)

• Deliver

  • 다양한 부하 분산 지원
  • 향상된 어플리케이션 스위칭
  • 세션/플로우 기반 스위칭
  • 정확한 서버 상태 모니터링
  • 지능적인 NAT 기능
  • 여러가지 기준의 지향성 적용
  • 서버 에러 응답 조정
  • IPv6 게이트웨이
  • 각종 Routing 지원
  • 지능적인 포트 미러링

• Optimize

  • SSL 가속
  • TCP 컨넥션 최적화
  • Layer 7 트래픽 QoS
  • 컨텐츠 스풀링/버퍼링
  • 컨텐츠 전송
  • 커넥션 가속
  • 지능적인 QoS
  • WAN 구간 최적화
  • 지능적인 HTTP 트래픽 압축

• Secure

  • 향상된 사용자 인증
  • 서버 리소스 은닉 기능
  • 쿠키 암호화
  • 선택적 컨텐츠 암호화
  • 어플리케이션 공격 차단
  • DoS 공격 및 SYN Flood 차단
  • L7 방화벽 - 패킷 차단
  • 어플리케이션 프락시 동작
  • Transaction Assurance
  • SSL-VPN
  • Advance WAF, ASM
  • SSL intercept
  • SSL Forward Proxy

• Cloud

  • Virtual Editions
  • Cloud Edition
  • vCMP
  • Open Stack plug-in
  • Cloud DoS 방어
  • SDN Gateway
  • Vmware NSX 연동
  • Cisco ACI module
  • Public, Private Cloud 환경 지원

BIP IP Switches

•
  i850
•
  i2800
•
  i2600
•
  i4800
•
  i4600

구분	i850	i2800	i2600	i4800	i4600
Interface	4 * 1G(SFP)	4 * 1G(SFP)	4 * 1G(SFP)	8 * 1G(SFP)	8 * 1G(SFP)
	2 * 10G(SFP)	2 * 10G(SFP)	2 * 10G(SFP)	4 * 10G(SFP)	4 * 10G(SFP)
최대 Throughput	2Gbps	10Gbps	10Gbps	20Gbps	20Gbps
L4 CPS	50K	250K	125K	450K	250K
L7 RPS	150K	650K	350K	1.1M	650k
Concurrent Connection	10M	14M	14M	28M	28M
Max SSL TPS(2K Key)	1K	4.3K	2.5K	20K	10K
Max SSL Throughput	1Gbps	8Gbps	5Gbps	15Gbps	10Gbps
Max Compression	1Gbps (Hardware)	5Gbps (Hardware)	3Gbps (Software)	10Gbps (Hardware)	6Gbps (Software)

•
  i5800
•
  i5600
•
  i7800
•
  i7600
•
  i10800
•
  i10600

구분	i5800	i5600	i7800	i7600	i10800	i10600
Interface	8 * 10G(SFP+)	8 * 10G(SFP+)	8 * 10G(SFP+)	8 * 10G(SFP+)	8 * 10G(SFP+)	8 * 10G(SFP+)
	4 * 40G(QSFP+)	4 * 40G(QSFP+)	4 * 40G(QSFP+)	4 * 40G(QSFP+)	6 * 40G(QSFP+)	6 * 40G(QSFP+)
최대 Throughput(L4/L7)	60G/35Gbps	60G/35Gbps	80G/40Gbps	80G/40Gbps	160G/80Gbps	160G/80Gbps
L4 CPS	800K	500k	1.1M	750K	1.5M	1M
L7 RPS	1.8M	1.1M	3M	1.8M	3.5M	2.1M
Concurrent Connection	40M	40M	80M	80M	100M	100M
Max SSL TPS(2K Key)	35K	20K	40K	22K	80K	37K
Max SSL Throughput	20Gbps	15Gbps	20Gbps	20Gbps	40Gbps	40Gbps
Max Compression	20Gbps (Hardware)	12Gbps (Hardware)	20Gbps (Hardware)	12Gbps (Hardware)	40Gbps (Hardware)	25Gbps (Hardware)

•
  i11800
•
  i11600
•
  i15800
•
  i15600

구분	i11800	i11600	i15800	i15600	Virtual Edition
Interface	8 * 10G(SFP+)	8 * 10G(SFP+)	8 * 40G(QSFP+)	8 * 40G(QSFP+)	Depend on H/W
	4 * 40G(QSFP+)	4 * 40G(QSFP+)	4 * 100G(QSFP28)	4 * 100G(QSFP28)
최대 Throughput(L4/L7)	160G/80Gbps	160G/80Gbps	320G/160Gbps	320G/160Gbps	200M ~ 1Gbps
L4 CPS	2.1M	1.1M	4.2M	2.4M	Depend on H/W
L7 RPS	5.5M	2.5M	10M	5M	Depend on H/W
Concurrent Connection	140M	140M	300M	300M	Depend on H/W
Max SSL TPS(2K Key)	80K	37K	160K	80K	Depend on H/W
Max SSL Throughput	40Gbps	40Gbps	50Gbps	50Gbps	Depend on H/W
Max Compression	40Gbps (Hardware)	25Gbps (Hardware)	60Gbps (Software)	30Gbps (Hardware)	Depend on H/W

•
  VIPRION 2200
•
  VIPRION 2400
•
  VIPRION 4480
•
  VIPRION 4800

구분	VIPRION 2200	VIPRION 2400	VIPRION 4480	VIPRION 4800
Slot	2	4	4	8
장착 가능 Blade	2250, 2150	2250, 2150	4450, 4340N, 4300	4450, 4340N, 4300

•
  2250 Blade
•
  2150 Blade
•
  4450 Blade
•
  4340N Blade
•
  4300 Blade

구분	2250 Blade	2150 Blade	4450 Blade	4340N Blade	4300 Blade
Interface	4 * 40G(QSFP+)	8 * 10G(SFP+)	6 * 40G(QSFP+)	8 * 10G(SFP+)	8 * 10G(SFP+)
			2 * 100G(QSFP28)	2 * 40G(QSFP+)	2 * 40G(QSFP+)
최대 Throughput(L4/L7)	80Gbps	40G/18Gbps	140Gbps	80G/40Gbps	80G/40Gbps
L4 CPS	1M	400K	2.9M	1.1M	1.4M
L7 RPS	2M	1M	5M	2M	2.5M
Concurrent Connection	48M	24M	180M	72M	36M
Max SSL TPS(2K Key)	44K	10K	160K	30K	30K
Max SSL Throughput	36Gbps	9Gbps	80Gbps	20Gbps	20Gbps
Max Compression	40Gbps	10Gbps (Hardware)	80Gbps	20Gbps	20Gbps
장착 가능 Chassis	2200, 2400	2200, 2400	4480, 4800	4480, 4800	4480, 4800
