Radware DefensePro & APSolute Vision DDoS Protection and Attack Mitigation

• DefensePro (LEGACY)

  • Blocking of study-based TCP/UDP/ICMP/IGMP Network Flood DDoS attack
  • Blocking of study-based DNS Query Flood DDoS attack
  • Blocking of application-based HTTP attack
  • Blocking of attempts of server cracking and hacking including Brute Force and Web Scan, etc.
  • Blocking of unknown worm propagation and scan attack
  • Automatic segregation on the malicious attack attempting IP
  • Blocking of Anomaly Packet, Fragmentation attack
  • Possible to set the threshold of the Connection Rate Limit and PPS Limit
  • Can support composition of Out-of-Path, and execute the detection and block at One-Box simultaneously without the need for separate detection equipment
  • Supports regular updating of the latest Global Signature Pattern (at the interval of 1 week)
  • Acquisition of EAL4 + International CC

Radware DefensePro (LEGACY)

•
  X06 Series
•
  X016 Series
•
  X412 Series
•
  X420 Series

Hardware Platform	X06 Series	X016 Series	X412 Series	X420 Series
Throughput	DP Model 506 - 500 Mbps DP Model 1006 - 1 Gbps DP Model 2006 - 2 Gbps	DP Model 1016 - 1 Gbps DP Model 2016 - 2 Gbps DP Model 3016 - 3 Gbps	DP Model 1412 - 1 Gbps DP Model 2412 - 2 Gbps DP Model 4412 - 4 Gbps DP Model 8412 - 8 Gbps DP Model 12412 - 12 Gbps	DP Model 10420 - 10 Gbps DP Model 20420 - 20 Gbps DP Model 30420 - 30 Gbps DP Model 40420 - 40 Gbps
Maximum accumulated sessions	2,000,000		4,000,000	6,000,000
Maximum DDoS defense performance	1,000,000 PPS		10,000,000 PPS	25,000,000 PPS
Whether DDoS dedicated chipset	-	O	O	O
Delay ratio	< 60 Micro Seconds
40GE optical port	-	-	-	4 (QSFP+)
10GE optical port	-	-	-	20 (SFP+)
1GE optical port	2 (SFP)	4 (SFP)	4 (SFP)	-
10/100/1000 UTP port	4	12	8	-
Operation mode	Transparent L2 Forwarding			Transparent L2 Forwarding IP Forwarding
Management console	RJ-45	RS-232		RJ-45
Hardware Bypass	optical port (need to purchase external Bypass separately) / UTP port (supports built-in Bypass function)
Whether IPv6 is supported	Support
Power source device	Can choose single/dualized power source device		Basically built-in dualized power source device
Size (W*D*H) and weight	424 * 457 * 44mm	424 * 600 * 44mm (1U) Dual PS: 424 x 600 x 88 mm (2U)	424 * 600 * 88mm	426 * 537 * 88mm
	(Single PS) / 7.2kg (Dual PS) / 8.7kg	(1U) / 9.5kg (2U) / 10.9kg	(2U) / 18kg	(2U) / 15.1 kg

• DefensePro (Next Generation)

  • Blocking of study-based TCP/UDP/ICMP/IGMP Network Flood DDoS attack
  • Blocking of study-based DNS Query Flood DDoS attack
  • Blocking of application-based HTTP attack
  • Automatic segregation on the malicious attack attempting IP
  • In-Box-SSL 기반 공격 방어
  • DNS 랜덤 서브도메인 공격 방어
  • Burst / Pulse 형태의 공격 방어
  • CDN 전용 정책 적용 방어
  • Blocking of Anomaly Packet, Fragmentation attack
  • Connection PPS Limit 임계치 설정 가능
  • Can support composition of Out-of-Path, and execute the detection and block at One-Box simultaneously without the need for separate detection equipment
  • Supports regular updating of the latest Global Signature Pattern (at the interval of 1 week)
  • Acquisition of EAL4 + International CC

Radware DefensePro (Next Generation)

•
  DefensePro 6
•
  DefensePro 20
•
  DefensePro 60
•
  DefensePro 200
•
  DefensePro 400

Categories	DefensePro 6	DefensePro 20	DefensePro 60	DefensePro 200	DefensePro 400
Throughput	DP Model 6-02 - 200 Mbps DP Model 6-05 - 500 Mbps DP Model 6-1 - 1 Gbps DP Model 6-2 - 2 Gbps DP Model 6-3 - 3 Gbps	DP Model 20-2 - 2 Gbps DP Model 20-4 - 4 Gbps DP Model 20-8 - 8 Gbps DP Model 20-12 - 12 Gbps	DP Model 60-10 - 10 Gbps DP Model 60-20 - 20 Gbps DP Model 60-40 - 40 Gbps	DP Model 200-80 - 80 Gbps	DP Model 400-160 - 160 Gbps
Maximum accumulated sessions	3,000,000	12,000,000		18,000,000
Maximum DDoS defense performance	5,800,000	25,000,000 PPS		330,000,000 PPS
Delay ratio	< 60 Micro Seconds
100GE optical port	-	-	-	4 (QSFP28)
40GE optical port	-	-	-	4 (QSFP+)
1GE / 10GE optical port	2 (SFP+)	24 (SFP+)		20 (SFP+)
10/100/1000 UTP port	6	-	-	-	-
Operation mode	Transparent L2 Forwarding / IP Forwarding
Management console	RJ-45
Hardware Bypass	optical port (need to purchase external Bypass separately) / UTP port (supports built-in Bypass function)	optical port (need to purchase external Bypass separately)
Whether IPv6 is supported	Support
Power source device	Basically built-in dualized power source device
Size (W*D*H) and weight	436 * 406 * 44mm	436 * 480 * 88mm (2U)		424 * 600 * 88mm
	(Single PS) / 6kg (Dual PS) / 7kg	11.2kg		18.7kg

•
  APSolute Vision ODS-VL2

Model Name	APSolute Vision ODS-VL2
CPU	1 x Intel Quad-CPU
Memory	32 GB
Port	2 x 10 GbE SFP+ 8 x 1 GbE RJ45
Management console	RJ-45
USB	On front panel
SSD	500 GB
Size (W*D*H) and weight	436 * 406 * 44mm (1U) / 6 kg
