| 구분 | EDA 10200 | EDA 9200 |
|---|---|---|
| Throughput | 100 Gbps | 50 Gbps |
| Packets per second (typical) | 10 million | 5 million |
| HTTP TPS | 3 million | 1.4 million |
| Total Endpoints | 100,000 | 50,000 |
| Throughput | 100 Gbps | 50 Gbps |
| Management ports | 2 x 1 GbE copper + 2 x 10 GbE fiber | 2 x 1 GbE copper + 2 x 10 GbE fiber |
| High Speed Monitoring Connectivity Options | 2 x 100 GbE/40 GbE MPO fiber (base) 4 x 100 GbE/40 GbE MPO fiber (option) 4 x 25 GbE/10 GbE LC fiber (option) 4 x customer-supplied DAC |
4 x 25 GbE/10 GbE LC fiber (option) 4 x customer-supplied SFP28 DAC |
| Datatore | 18 TB (RAID 10) | 7.2 TB (RAID 10) |
| Packet capture (optional) | 480 GB | 480 GB |
| Power supply | 2 x 1000 W | 2 x 750 W |
| Height | 8.68 cm (3.42 in.) | 8.68 cm (3.42 in.) |
| Width | 43.4 cm (17.09 in.) | 43.4 cm (17.09 in.) |
| Depth | 71.6 cm (28.17 in.) | 71.6 cm (28.17 in.) |
| Weight | 26.3 kg (57.98 lb) | 26.3 kg (57.98 lb) |
| 구분 | EDA 8200 | EDA 6200 | EDA 1100 |
|---|---|---|---|
| Throughput | 25 Gbps | 10 Gbps | 1 Gbps |
| Packets per second (typical) | 2.5 million | 1 million | up to 242,000 |
| HTTP TPS | 795,000 | 440,000 | up to 118,000 |
| Total Endpoints | 35,000 | 18,000 | 750 |
| Throughput | 25 Gbps | 10 Gbps | 1 Gbps |
| Management ports | 4 x 1 GbE copper | 4 x 1 GbE copper | 1000BASE-T |
| High Speed Monitoring Connectivity Options | 2 x 25 GbE/10 GbE LE fiber 2 x customer-supplied SFP28 DAC |
2 x 10 GbE LC fiber 2 x customer-supplied SFP+ DAC |
NA |
| Datatore | 7.2 TB (RAID 10) | 1.2 TB (RAID 10 optional) | 88 GB |
| Packet capture (optional) | 480 GB | 480 GB | 140 GB |
| Power supply | 2 x 750 W | 2 x 750 W | Max 55 W consumption DC adapter |
| Height | 4.28 cm (1.68 in.) | 4.28 cm (1.68 in.) | 5.7 cm (2.24 in.) |
| Width | 43.4 cm (17.08 in.) | 43.4 cm (17.08 in.) | 19.6 cm (7.71 in.) |
| Depth | 73.4 cm (29.61 in.) | 73.4 cm (29.61 in.) | 27.0 cm (10.6 in.) |
| Weight | 21.9 kg (48.28 lbs) | 21.9 kg (48.28 lbs) | 3.2 kg (7.0 lbs) |
