네트워크 인프라 솔루션
Network Infrastructure Solution 네트워크 인프라 솔루션

네트워크 인프라 솔루션
L4-L7 로드밸런싱, WAN가속, 인텔리전트 트래픽 관리, DNSㆍDHCPㆍIP 관리 등 글로벌 리딩 네트워크 인프라 솔루션
F5 Networks Radware Alteon Extrahop Packetlogic Infoblox
Packetlogic
  • 브로슈어
  • 연락처
    이영민 부장T. 02-3404-5641
  • 메일

차세대 지능형 트래픽 통합관리 솔루션
(“QoS + 업무 서비스 품질 향상 + 보안사고 위협관리 + Traffic 유발 요소관리”)

PRE(PacketLogic Real-time Enforcer) Platforms

구분 PL8840 PL8920 PL8960 PL9420 PL15000
Throughput 32Gbps 50Gbps 70Gbps 120Gbps 600Gbps
Connections 15,000,000 15,000,000 20,000,000 30,000,000 240,000,000
Connection Per Second 220,000 300,000 400,000 500,000 4,800,000
Subscribers 2,000,000 3,000,000 3,000,000 3,000,000 10,000,000
Bandwidth Licensing 1Gbps ~10Gbps increments 1Gbps ~ 10Gbps increments 1Gbps ~ 10Gbps increments 1Gbps, 10Gbps ~ 100Gbps increments 1Gbps, 10Gbps ~ 100Gbps increments
Number of channels 8x 10GE or 16x GE 24x GE or 12x 10GE 24x GE or 12x 10GE 32x GE or 16x 10GE 24 x 10GE SFP+
SR/LR/ER (48-Ports)
or 3 x 100GE
LR4/SR10 CFP2
(6-Ports)
Physical Interface 1000Base-T,
1000Base-SX
1000Base-LX,
10Gbase-SR
10Gbase-LR
1000Base-T,
1000Base-SX
1000Base-LX,
10Gbase-SR
10Gbase-LR
1000Base-T,
1000Base-SX
1000Base-LX,
10Gbase-SR
10Gbase-LR
1000Base-T,
1000Base-SX,
1000Base-LX,
10Gbase-SR,
10Gbase-LR,
10Gbase-ER RJ-45
10Gbase-SR,
10Gbase-LR,
10Gbase-ER,
100GE CFP2 LR4/SR10
Redundancy Bypass, FlowSync Bypass, FlowSync Bypass, FlowSync Bypass, FlowSync Bypass, Internal Modules, FlowSync

PIC(PacketLogic Intelligent Center) Platforms

구분 PL1620 PL1640 PL1650
System Disk space 2 x 1TB HDD or 5 x 1TB HDD (RAID1) 2 x 1TB HDD or 5 x 1TB HDD (RAID1) 2 x 1TB HDD or 5 x 1TB HDD (RAID1)
Memory 32GB 128GB 384GB
Subscribers 2,000,000 5,000,000 5,000,000
Interfaces 4x 10/100/1000 Base-T Ethernet port 4x 10/100/1000 Base-T Ethernet port 4x 10/100/1000 Base-T Ethernet port
Internal Add-On Options 2x1TB 7.2K RPM NLSAS RAID1
6x1TB 7.2K RPM NLSAS RAID6
2-Port 10GE SFP+
H830 External RAID Controller
6x1TB 7.2K RPM NLSAS RAID6
6x1.2TB 10K RPM NLSAS RAID10
2x200GB Solid State Drive SAS Write Intensive
MLC RAID1
2-Port 10GE SFP+
H830 External RAID Controller
6x1TB 7.2K RPM NLSAS RAID6
6x1.2TB 10K RPM NLSAS RAID10
2x200GB Solid State Drive SAS Write Intensive
MLC RAID1
